Mano Sriram

clawdbot_header

Main elements which drive clawdbot:

  1. Gateway and Nodes
  2. Memory and Context Compaction
  3. Agent Runtime and SubAgents
  4. Channels
  5. Skills
  6. Hooks
  7. Plugins
  8. Templates (AGENTS.md, BOOT.md, HEARTBEAT.md, IDENTITY.md, SOUL.md, TOOLS.md, USER.md)

Gateway

This is the main server that handles requests from cli and acts as a control plane for all integrations (macOS, web UI, telegram, whatsapp, etc…).

Acts as a websocket handler that emits events like agent, chat, presence, healthcheck, cron, etc…

Nodes (macOS / iOS / Android / headless)

Any client connecting to the gateway with role: node is considered to be a node.

ref: https://docs.openclaw.ai/concepts/architecture#overview

Memory

There are 2 memory layers (files):

  1. memory/YYYY-MM-DD.md: Stores that day’s memory writings. This is retrieved when session starts.

  2. MEMORY.md: Long Term memory storage. User can store things by saying “Remember this” or “Write it down” or something like that.

ref: https://docs.openclaw.ai/concepts/memory#memory-files-markdown

Compaction

Older context history is removed by removing older history but just keeping the summary of the old context history which takes much lesser space/tokens. This is done automatically (auto-compaction) or by calling /compact manually.

ref: https://docs.openclaw.ai/concepts/compaction

Agent runtime and SubAgents

Agent runtime is the core loop which takes care of agentic actions like taking inputs, building prompt/context, manage state.

clawdbot reuses runtime components from pi-mono (https://github.com/badlogic/pi-mono), only the main parts are derived from pi-mono. Everything else is implemented by clawdbot itself.

SubAgents are agents/processes spawned by the main agent so that the main loop isn’t blocked. By default, the subagents do not get complete tool access as of the main agent, its a bit restricted to prevent uncontrolled “agent-of-agents explosion”.

ref: https://docs.openclaw.ai/cli/agents

Channels

Channels are a way to manage channel accounts (telegram, whatsapp, etc…) and their status on the gateway. For example,

openclaw channels add --channel telegram --token <bot-token> is used to add a telegram channel. ref: https://docs.openclaw.ai/cli/channels

Skills

clawdbot uses separate dir for each skill.

Skill is something the bot can learn and do work upon. Each skill dir will have a SKILL.md file which contains information about the skill.

Shared skills (skills accessed by all agent instances of clawdbot) are stored in ~/.clawdbot/skills whereas skill for a specific agent instance is stored at /skills directory.

External skills are considered as untrusted code since it has the ability to make the clawdbot do things which are not enabled by default.

ref: https://docs.openclaw.ai/tools/skills#skills

Hooks

Hooks trigger when something is done by the agent. They run inside the gateway, with the custom hook having its own dir like this:

my-hook/
├── HOOK.md          # Metadata + documentation
└── handler.ts       # Handler implementation

This hook is automatically triggered as per the handler.ts above. The HOOK.md file is of the structure: markdown

---
name: my-hook
description: "Short description of what this hook does"
homepage: https://docs.openclaw.ai/hooks#my-hook
metadata:
  { "openclaw": { "emoji": "🔗", "events": ["command:new"], "requires": { "bins": ["node"] } } }
---

# My Hook

Detailed documentation goes here...

## What It Does

- Listens for `/new` commands
- Performs some action
- Logs the result

## Requirements

- Node.js must be installed

## Configuration

No configuration needed.

Refer handler-implementation for handler.ts example.

Plugins

A Plugin is just a piece of code (ts modules) that extends the functionality of openclaw. This is a list of available plugins as of now. All plugins run in-process with the gateway, so the code/plugin is considered as trusted. ref: https://docs.openclaw.ai/plugin

Templates

This is a list of templates (instructions editable by user) for the clawdbot to follow all the time.

AGENTS.md is a guide on how clawdbot should start and behave during sessions. It covers:

  1. First Run
  2. Memory
  3. Safety
  4. Group Chats
  5. Know When to Speak!
  6. React like a Human!
  7. Tools
  8. Heartbeat vs Cron
  9. Memory maintenance

SOUL.md tells the bot about who it is and what are the ethical rules it must follow. This file tells about the type of soul of the bot.

IDENTITY.md tell about yourself (the user). Who you are and what kind of person are you. The bot remembers this when conversing with the user.

BOOTSTRAP.md is the file/memory which the bot reads after waking up or starting up. This document contains links to other templates.

BOOT.md First Instructions to follow on bootup/start.

TOOLS.md Summary of the user’s preferences and setup of clawdbot for itself to understand how you work.

ref: https://docs.openclaw.ai/reference/templates

written for x.com/manosriram: article
